Name：TWT-Speed regulating brake motor
Type | Output (W) | Voltage (V) | Starting torque (g-cm) | Rated torque (g-cm) | Rated current (A) | Capacitor (U.F) |
Appropriate reducer | Maximum allowable load (kg-cm) | ||
Round shaft | Gear shaft | |||||||||
4RK25RA-AM | 4RK25RGN-AM | 25 | 110 | 1400 | 300-1600 | 0.9 | 8 | 4GN□ | 4GN□K | 80 |
4RK25RA-CM | 4RK25RGN-CM | 25 | 220 | 1400 | 300-1600 | 0.45 | 1.5 | 4GN□ | 4GN□K | 80 |
5RK40RA-AM |
5RK40RGN-AM | 40 | 110 | 2400 | 1000-2500 | 1.6 | 14 | 5GN□ | 5GN□K | 100 |
5RK40RA-CM | 5RK40RGN-CM | 40 | 220 | 2400 | 1000-2600 | 0.8 | 3 | 5GN□ | 5GN□K | 100 |
5RK60RA-AM | 5RK60RGN-AM | 60 | 110 | 3000 | 1100-3500 | 1.8 | 16 | 5GN□ | 5GN□K | 100 |
5RK60RA-CM | 5RK60RGN-CM | 60 | 220 | 3000 | 1000-3500 | 0.9 | 3.5 | 5GN□ | 5GN□K | 100 |
-------- | 5RK60RGU-AM | 60 | 110 | 3000 | 1100-3500 | 1.8 | 16 |
---- | 5GU□K | 150 |
-------- | 5RK60RGU-CM | 60 | 220 | 3000 | 1100-3500 | 0.9 | 3.5 |
---- | 5GU□K | 150 |
5RK90RA-AM | 5RK90RGU-AM | 90 | 110 | 3600 | 1200-4000 | 2 | 25 |
---- | 5GU□K | 250 |
5RK90RA-CM | 5RK90RGU-CM | 90 | 220 | 3600 | 1200-4000 | 1 | 5 |
---- | 5GU□K | 250 |
5RK120RA-AM |
5RK120RGU-AM | 120 | 110 | 6300 | 2500-6500 | 4 | 25 |
---- | 5GU□K | 250 |
5RK120RA-CM | 5RK120RGU-CM | 120 | 220 | 6300 | 2500-6500 | 2 | 6 |
---- | 5GU□K | 250 |
Note:1.Frequency(Hz)50/60,Pole number:(P)4,Revolution(Rpm)1450/1750,Rated time:(min)30
