Name：TWT-Reversible motor
Single phase 110V
Type | Output (w) | Starting torque (g.cm) | Rated torque (g.cm) | Rated current (A) | Capacitor (uF) |
Appropriate reducer | Maximum allowable load (kg.cm) | ||
Round shaft | Gear shaft | ||||||||
2RK6A-A | 2RK6GN-A | 6 | 450 | 370 | 0.24 | 2.5 | 2GN□ | 2GN□K | 25 |
3RK15A-A | 3RK15GN-A | 15 | 900 | 900 | 0.52 | 4 | 3GN□ | 3GN□K | 50 |
4RK25A-A | 4RK25GN-A | 25 | 1500 | 1500 | 0.9 | 8 | 4GN□ | 4GN□K | 80 |
5RK40A-A | 5RK40GN-A | 40 | 2600 | 2600 | 1.6 | 14 | 5GN□ | 5GN□K | 100 |
5RK60A-AF | 5RK60GN-AF | 60 | 3600 | 3800 | 1.8 | 16 | 5GN□ | 5GN□K | 100 |
5RK60GU-AF | 60 | 3600 | 3800 | 1.8 | 16 | ——— | 5GU□K | 200 | |
5RK90A-AF | 5RK90GU-AF | 90 | 4520 | 5500 | 2.3 | 25 |
— — | 5GU□K | 200 |
5RK120A-AF | 5RK120GU-AF | 120 | 5500 | 6600 | 2.5 | 25 |
— — | 5GU□K | 200 |
Note:Frequency(Hz)50/60,Pole number:(P)4,Revolution (Rpm)1450/1750,Rated time:(min)30 continue
Single phase 220V
Type | Output (w) | Starting torque (g.cm) | Rated torque (g.cm) | Rated current (A) | Capacitor (uF) |
Appropriate reducer | Maximum allowable load (kg.cm) | ||
Round shaft | Gear shaft | ||||||||
2RK6A-C | 2RK6GN-C | 6 | 450 | 370 | 0.12 | 0.8 | 2GN□ | 2GN□K | 25 |
3RK15A-C | 3RK15GN-C | 15 | 900 | 900 | 0.29 | 1.2 | 3GN□ | 3GN□K | 50 |
4RK25A-C | 4RK25GN-C | 25 | 1500 | 1500 | 0.45 | 1.5 | 4GN□ | 4GN□K | 80 |
5RK40A-C | 5RK40GN-C | 40 | 2600 | 2600 | 0.8 | 3 | 5GN□ | 5GN□K | 100 |
5RK60A-CF | 5RK60GN-CF | 60 | 3600 | 3800 | 0.9 | 3.5 | 5GN□ | 5GN□K | 100 |
5RK60GU-CF | 60 | 3600 | 3800 | 0.9 | 3.5 |
——— | 5GU□K | 150 | |
5RK90A-CF | 5RK90GU-CF | 90 | 4900 | 5500 | 1.4 | 5 | —— | 5GU□K | 200 |
5RK120A-CF | 5RK120GU-CF | 120 | 5300 | 6100 | 1.6 | 6/8 |
—— | 5GU□K | 200 |
5RK150A-CF | 5RK150GU-CF | 150 | 6200 | 9400 | 1.9 | 8/10 |
—— | 5GU□K | 200 |
Note:Frequency(Hz)50/60,Pole number:(P)4,Revolution (Rpm)1450/1750,Rated time:(min)30 Continue, 180w motor be customized.
